● High cooling efficiency: The unique inclined staggered structure design increases the length and tortuosity of the water flow path, extending the residence time of cooling water in the packing. Meanwhile, it enlarges the contact area and duration between water and air, enabling more sufficient heat exchange and thus significantly enhancing the cooling effect.
● Low resistance: The rational structural layout allows smooth air flow through the packing layer with low ventilation resistance, which can reduce fan energy consumption and lower operating costs.
● Not easy to clog: The inclined staggered packing has a large sheet spacing and uniform water distribution, with few dead zones for water flow. This prevents impurities and suspended solids in water from accumulating and settling, effectively avoiding clogging and ensuring long-term stable operation of the packing.
● Good chemical stability: Usually made of materials such as polyvinyl chloride (PVC) or polypropylene (PP), it has excellent resistance to acids, alkalis, and organic solvent corrosion. It can adapt to different water qualities and working environments, with a long service life.
● Strong hydrophilicity: It has good hydrophilic properties, allowing cooling water to form a uniform water film on the packing surface, increasing the contact area between water and air, and improving heat and mass transfer efficiency.
● Easy assembly: Generally assembled in two forms: coil materials and screw rods. The installation process is simple and fast, which can greatly shorten the construction period.
● Length: Common specifications include 1000mm, 1250mm, 1500mm, 2000mm, etc.
● Width: Usually 500mm.
● Plastic sheet thickness: Generally between 0.35mm-0.4mm.
● Hole spacing: Available in different specifications such as 30mm, 35mm, 40mm, etc.
● Weight capacity per cubic meter of assembled packing: 15.5kg-18.5kg.
● Industrial cooling towers: Widely used in cooling towers in industrial fields such as petroleum, chemical engineering, metallurgy, electric power, and textiles. It is used to cool circulating water and ensure the normal operation of industrial production equipment.
● Central air conditioning systems: In central air conditioning systems of large buildings, inclined staggered packing can be used in cooling towers to help reduce the temperature of air conditioning circulating water, improve the refrigeration efficiency of the air conditioning system, and lower energy consumption.
● Other fields: It can also be applied in some cooling processes, such as cooling related equipment in the production processes of pharmaceutical, food and beverage, papermaking industries, etc., to ensure the smooth progress of production.
